Technical Specifications
Overview
Dimensions
Without mount: ⌀80 x 89 mm (⌀3.1 x 3.5") With mount: ⌀80 x 153 mm (⌀3.1 x 6") M. Zuiko Digital ED 17 mm PRO: ⌀68.2 x 87 mm (⌀2.7 x 3.4") M. Zuiko Digital ED 45 mm PRO: ⌀70 x 84.9 mm (⌀2.8 x 3.3") Outdoor case: ⌀91.6 x 196.3 mm (⌀3.6 x 7.7")
Face Recognition Yes
License Plate Recognition Yes
Smart Detections (People, Vehicles, Animals) Yes
Resolution 4K
Field of View
M. Zuiko Digital ED 17 mm PRO: H: 52°, V: 39°, D: 65° M. Zuiko Digital ED 45 mm PRO: H: 21.6°, V: 16.2°, D: 27°
Audio Two-way audio
Weatherproofing IPX5 (With the outdoor case)
Mounting Wall, pole mount (Included) Tripod mount (Optional)
UniFi Application Suite Protect
Performance
Networking Interface
GbE RJ45 port
Video
Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR/3DNR/NR by motion, masking, text overlay
Max. Frame Rate 30 FPS
Resolution 8MP 3840 x 2160 (16:9)
Optics
Sensor 4/3" 10MP CMOS
Lens
M. Zuiko Digital ED 17 mm ƒ/1.2 PRO M. Zuiko Digital ED 45 mm ƒ/1.2 PRO
Hardware
Max. Power Consumption
17.77W (With lens working)
Supported Voltage Range
37—57V DC
Power Method
PoE+
Processor
Quad-core Arm® Cortex®-A53 based chip
Pole Mount Diameter
1.5–2" (38–50 mm)
Weight
Without mount: 660 g (1.5 lb) With mount: 820 g (1.8 lb) M. Zuiko Digital ED 17 mm PRO: 390 g (0.9 lb) M. Zuiko Digital ED 45 mm PRO: 410 g (0.9 lb) Outdoor case: 510 g (1.1 lb)
Enclosure Material
Aluminum alloy
Mount Material
Wall mount: aluminum alloy Pole mount: aluminum alloy
Button
(1) Factory reset (1) Lens release key
Ambient Operating Temperature
-20 to 40° C (-4 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
NDAA Compliant
Yes
Certifications
CE, FCC, IC
